Gold Coast's explosive growth from a small holiday town to a major city has pushed development onto areas that were once floodplains, swamps, and sand ridges. Many residential and commercial plots now sit on engineered fill placed over soft alluvial clays or coastal sands. Understanding how that fill behaves under load is critical. We have analyzed dozens of sites across the city, from Broadbeach to Coomera, and seen everything from poorly compacted fill to imported material with variable grading. Before you design a slab or footing, you need to know if the fill will settle evenly. That is where foundations on fill analysis comes in. We combine test pits, SPT, and plate load tests to evaluate the actual state of the fill. For deeper fill layers we often recommend a MASW-Vs30 survey to map stiffness variations across the site without drilling every corner.
A fill that looks compact on the surface can hide a loose layer two metres down. Only thorough testing reveals the real settlement risk.
Methodology and scope
- Standard compaction tests (AS 1289.5.1.1)
- Moisture-density relationship (AS 1289.5.4.1)
- Plate load test (AS 1289.6.3.1)
- SPT blow counts in fill and underlying soil
- Atterberg limits on cohesive fill samples
Local considerations
Gold Coast sits in a subtropical climate with intense summer rainfall and a high water table near the coast. That combination is tough on fill. When heavy rain hits, loose fill can collapse suddenly, causing differential settlement under slabs and footings. The risk is highest in older subdivisions where fill was placed without modern compaction control. We have seen cases in Helensvale and Pimpama where fill that tested fine in dry conditions lost half its bearing capacity after a wet season. Our foundations on fill analysis includes a collapse potential test and a check of the groundwater regime. If the site is near a canal or lake, we also recommend geotechnical drainage to keep the fill dry long-term.
Explanatory video
Applicable standards
AS 1726:2017 Geotechnical site investigations, AS 2870:2011 Residential slabs and footings, AS 1289.5.1.1 Compaction control (Standard Proctor)
Associated technical services
Fill Compaction Assessment
Field density tests, moisture content, and compaction curve verification for existing fill. We sample at multiple depths to detect layers of poor compaction and provide a clear pass/fail report per AS 1289.
Settlement & Bearing Capacity Study
Combines SPT, plate load testing, and consolidation analysis to estimate total and differential settlement under design loads. Includes recommendations for foundation type — shallow footing, raft slab, or deep foundation if fill is too thick or variable.
Typical parameters
Frequently asked questions
How deep do you test fill for foundations on fill analysis?
We test to the full depth of the fill layer plus at least 1.5 metres into the natural soil beneath. In Gold Coast, fill depths commonly range from 1 m to 4 m, so boreholes or test pits go 3 m to 6 m deep. We adjust the depth based on the building load and the underlying geology.
Can I build directly on fill without analysis?
It is risky. Uncontrolled or poorly compacted fill can settle unevenly, crack slabs, and damage structures. AS 2870 requires that fill be assessed for compressibility and collapse potential. Skipping the analysis often leads to expensive remedial work later.
What tests are most important for fill in Gold Coast?
Plate load test, SPT, compaction control, and Atterberg limits are the key ones. In areas with a high water table, we also run collapse potential tests. The plate load test is especially useful because it measures the actual stiffness of the fill under a simulated footing.
How much does foundations on fill analysis cost in Gold Coast?
The cost typically ranges between AU$1.230 and AU$4.130 depending on the number of test points, depth of investigation, and complexity of the fill. A standard single-house assessment with three test pits and basic lab work is on the lower end, while larger commercial sites with SPT and plate load testing are on the higher end.
